37
Extract from the spare parts list
Use only original MAKITA parts. For repairs and
replacement of other parts, see your MAKITA service center.
EA3200S, EA3201S
EA3202S, EA3203S
Pos. Qty. Denomination
1 1 Sprocket nose bar 3/8”, 30 cm, 1.3 mm (12”)
1 Sprocket nose bar 3/8”, 35 cm, 1.3 mm (14”)
1 Sprocket nose bar 3/8”, 40 cm, 1.3 mm (16”)
2 1 Saw chain 3/8” for 30 cm, 1.3 mm
1 Saw chain 3/8” for 35 cm, 1.3 mm
1 Saw chain 3/8” for 40 cm, 1.3 mm
1 1 Sprocket nose bar 3/8”, 30 cm, 1.1 mm (12”)
1 Sprocket nose bar 3/8”, 35 cm, 1.1 mm (14”)
2 1 Saw chain 3/8” for 30 cm, 1.1 mm
1 Saw chain 3/8” for 35 cm, 1.1 mm
1 1 Sprocket nose bar 3/8”, 30 cm, 1.3 mm (12”)
1 Sprocket nose bar 3/8”, 35 cm, 1.3 mm (14”)
1 Sprocket nose bar 3/8”, 40 cm, 1.3 mm (16”)
2 1 Saw chain 3/8” for 30 cm, 1.3 mm
1 Saw chain 3/8” for 35 cm, 1.3 mm
1 Saw chain 3/8” for 40 cm, 1.3 mm
1 1 Sprocket nose bar 3/8”, 30 cm, 1.1 mm (12”)
1 Sprocket nose bar 3/8”, 35 cm, 1.1 mm (14”)
2 1 Saw chain 3/8” for 30 cm, 1.1 mm
1 Saw chain 3/8” for 35 cm, 1.1 mm
3 1 Chain protector for 30‑35 cm (3/8”)
1 Chain protector for 40 cm (3/8”)
4 1 Universal wrench SW 16/13
6 1 Carburetor screwdriver
7 1 Suction head
8 1 Fuel tank cap, cpl.
9 1 O‑Ring 29.3 x 3.6 mm
10 1 Return spring pack, complete
11 1 Spring
12 1 Driver
13 1 Starter cable 3.5 x 900 mm
14 1 Spark plug
15 1 Oil tank cap, cpl.
16 1 O‑Ring 29.3 x 3.6 mm
17 1 Air lter
18 1 Sprocket guard, cpl.
1 Sprocket guard (with fast tensioner), complete
19 2 Hexagonal nut M8
20 1 Clutch drum cpl. 3/8”, 6‑tooth
21 1 Cup washer
22 1 Circlip
Accessories (not delivered with the chain saw)
25 1 Chain gauge, type 092 (91VG), 492 (91PX)
25 1 Chain gauge, type 290 (90SG)
26 1 File handle
27 1 Round le, dia. 4.5 mm
28 1 Round le, dia. 4.0 mm
29 1 Flat le
30 1 File holder
(with round le dia. 4.5 mm)
31 1 File holder
(with round le dia. 4.0 mm)
32 1 Oset screwdriver
‑ 1 Combined can
(for 5l fuel, 2.5l chain oil)
Spare parts
