P a g e | 139

GXV3240 User Guide

PNP

The GXV3240 has built in PNP (Plug and Play) application to mass provision for other Grandstream phone

clients. The PNP feature is for other phones to be able to find the configuration path and download their

configuration settings with little or no configurations from GXV3240. It gives the GXV3240 phone

accessibility to many phones’ settings and features that can be configured, making it unnecessary to

configure these settings on other phones themselves.

Set Up PNP Application

It needs to configure the Account 1’s setting properly before implementing the PNP feature on GXV3240.

1. Check the Account Active box for Account 1.

2. In Account 1’s SIP setting page, disable the Validate Incoming SIP Messages feature.

3. In Account 1’s SIP setting page, set the SIP transport protocol to UDP.

4. In the Account 1’s SIP setting page, do not use 5060 as the Local SIP Port. This setting will be

overridden to 0 automatically when the PNP feature is enabled. The port number with 0 refers the port

number will be random.

Enable PNP Feature

After the settings above, end users can enable the PNP feature for GXV3240. It can be enabled from the

web page or from the LCD screen.

Enable from Web Page

1. Log in the GXV3240 web page, browse to Maintenance Upgrade.

2. Check the Enable PNP Feature box.

3. In the PNP URL box, type the URL path for the saved configuration file with protocol identifier. For

example, http://192.168.1.200/config. The protocol identifier can be selected from tftp, http, and https.

4. GXV3240 supports the built-in httpd server feature. End users can save the config file in the GXV3240

device and it can be set as a file server transport the files to other phone client. If end user needs this

feature, the config file should be saved in the directory /Internal Storage/pnp. And the PNP URL should

be point to the pnp directory. For instance, if a user wants to set his GXV3240 as a HTTP file server,

whose IP address is 192.168.1.100, and the config file is saved in the directory /Local Storage/pnp, it

needs to enter http://192.168.1.100/pnp. If it needs to transport the file via HTTPS, it needs to set the

Access Method to HTTPS under the page of MaintenanceWeb/SSH Access.

5. Then save the setting and reboot the unit. If the Account 1’s Local SIP port does not be set to 0, the

phone system will pop up a prompt window and it writes “The local SIP port is 5060 in your account,

save the operation will change the port to the random one, sure to change?” Click OK to change to port

from 5060 to 0 by force.
