P a g e | 49
GXV3240 User Guide
Dial A Number Directly
1. Use the methods mentioned above to open dial screen [Figure 29: GXV3240 Dial Screen].
2. Select the account to dial out on the left panel of the dial screen. The selected account will be
highlighted in grey background.
3. Enter the digits to be dialed out using the keypad. If the digit matches call history, a dropdown list of
numbers will be displayed for users to select.
4. Tap on (audio call only) or (video call), or (audio call only) to send the
number. If no key is pressed, the call will be automatically dialed out after 4 seconds timeout.
Note:
By default, the "No Key Entry Timeout" is 4 seconds, meaning if no key is pressed after starting
entering number, the call will be automatically sent out after the timeout. The timeout interval can be
configured under web GUI->Account->Call Settings.
GXV3240 allows users to press # key as SEND key. This behavior can be disabled via option "Use #
as Dial Key" under web GUI->Account->Call Settings.
When the user enters the digit on the dial screen, if there is digit matching call history, or contacts
name/number, the drop-down list will show the numbers. For example, if "John" is saved in the
contacts, entering 5 (JKL) 6 (MNO) 4 (GHI) 6 (MNO) will show call log with 5646 as the first four digits,
as well as John's number. Users could then directly select one of them from the list, instead of entering
all the digits.
Redial
Users can dial out the last dialed number if there is dialed call log, using the same SIP account making the
call last time. There are two ways to redial the last dialed number.
When the phone is idle or off hook, press SEND button to redial.
When the phone is on hook, press SEND button or # button (# key is used as dial key).
Dial A Number Via Contacts
Follow the steps below to dial a number via Contacts.
1. Access Contacts by tapping on icon on the bottom of the idle screen, or selecting from
phone's menu.
2. Navigate in the contacts entries by sliding up/down on the screen.
3. Tap on the dial icon for the contact .
