P a g e | 20
GXV3240 User Guide
GXV3240 Technical Specifications
The following table resumes all the technical specifications including the protocols / standards supported,
voice codecs, telephony features, languages and upgrade/provisioning settings for the GXV3240 phone.
Table 2: GXV3240 Technical Specifications
Protocols/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A
record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE,
LLDP-MED, LDAP, TR-069, 802.1x, TLS, SRTP
Network Interfaces
Dual switched 10/100/1000 Mbps ports with integrated PoE
Graphic Display
4.3"(480*272) capacitive (5 points) touch screen TFT LCD
Camera
Tiltable mega pixel CMOS camera privacy shutter
Bluetooth
Yes, integrated. Bluetooth 4.0 + EDR
Wi-Fi
Yes, integrated. 802.11b/g/n
Auxiliary Ports
RJ9 headset jack (allowing EHS with Plantronics headsets), 3.5mm stereo
headset with microphone, dual USB ports, SD, mini HDMI
Feature Keys
11 function keys for PHONEBOOK, BACKSPACE, HEADSET, MUTE, HOLD,
MESSAGE, TRANSFER, CONFERENCE, SPEAKERPHONE, SEND/REDIAL,
VOLUME. 3 dedicated Android keys for HOME, MENU, and BACK
Voice Codec
Support for G.711µ/a, G.722 (wide-band), G.726-32, G.729, iLBC, OPUS,
in-band and out-of-band DTMF (In audio, RFC2833, SIP INFO)
Video Codec and
Capabilities
H.264 BP/MP/HP, H263, video resolution up to 720p HD, frame rate up to 30 fps,
bit rate up to 2Mbps, 3-way video conference, anti-flickering, auto focus and auto
exposure, PIP (Picture-in-Picture), on-screen-display, camera block, still picture
capture/store, video recording, visual voice message indicator
Telephony Features
Hold, transfer, forward (unconditional/no-answer/busy), call park/pickup, 6-way
audio conference, shared-call-appearance (SCA) / bridged-line-appearance
(BLA), virtual MPK, downloadable phone book (XML, LDAP), call waiting, call
history, boss-secretary virtual button, flexible dial plan, hot desking, personalized
music ringtones, server redundancy & fail-over
Sample Applications
Skype, Google Hangouts, Microsoft Lync, Web browser, GoToMeeting,
Facebook, Twitter, Youtube, news, weather, stock, Internet Radio, Pandora,
Last.fm, Yahoo Flickr, Photo bucket, alarm clock, Google calendar, mobile phone
data import/export via Bluetooth, etc. API/SDK available for advanced custom
application development
Applications
Deployment
Allow various Android operating system 4.2 compliant applications to be
developed, downloaded and run in the embedded device with provisioning
control
HD Audio
Yes, both handset and speakerphone support HD (wide-band) audio
Base Stand
Yes, integrated stand with multiple adjustable angles. Wall mountable
