GXV3240 User Guide

Download Contacts

The GXV3240 supports downloading XML phonebook from a remote HTTP/HTTPS/TFTP server to local

Contacts. When downloading the phonebook, the GXV3240 sends request to the HTTP/HTTPS/TFTP

server looking for file phonebook.xml. For more details about GXV3240 phonebook, please refer to the

following link:

http://www.grandstream.com/products/gxv_series/gxv3240/documents/gxv3240_xml_phonebook_guide.pdf

To download phonebook:

1. Make sure the GXV3240 can connect to the HTTP/HTTPS/TFTP server and the phonebook.xml file in

correct format is downloadable from the HTTP/HTTPS/TFTP server.

2. Open Contacts.

3. Tap on the upper right of the Contacts screen.

4. Select "Download" to bring up the "Download Contacts" dialog.

Figure 74: GXV3240 Contacts - Download Contacts

5. Fill in the necessary options and then tap on "Download Now". The GXV3240 will send out request to

the configured HTTP/TFTP server.

Search Contacts

1. Open Contacts.

2. Select or to open the contact list where you would like to search.

3. Tap on the upper right to bring up search dialog.

4. Enter contact's name or number to search. The search result will be automatically updated and

displayed when entering the key words.
