MAKE PHONE CALLS

The GXV3240 supports up to 6 independent SIP accounts, including a pre-configured IPVideoTalk

account registered on account 6. Users can make video calls and send messages to other IPVideoTalk

accounts registered on another GXV32xx/GXV31xx. Each account can have separate SIP servers,

usernames and NAT configurations.

Account Status

On the idle screen, the account widget shows account name, number and registration status.

 The following figure shows the accounts are successfully registered (account icon is green).

 If the account icon is grey, it's still trying to register or unable to register.

 If the users have enabled Shared Call Appearance on the registered account, the account icon will be

blue .

 Microsoft Lync account and Bluetooth handsfree profile account will be displayed here too (if any).

Figure 28: GXV3240 Account Widget

Note: Users may go to web UI -> Maintenance -> Network Settings, uncheck “Show IP Address On

Account Widget” to hide the IP address of the phone.

Configure SIP Account

To register SIP account, users could directly configure from phone's LCD menu->Settings->Advanced

Settings->Account. Or users could log in the GXV3240 web GUI->Account page to fill in the necessary

registration information, i.e., Account active, Account name, SIP Server, SIP User ID, SIP Authentication

ID, SIP Authentication Password, etc. Once the correct information is entered and saved, the account

registration status will show on the main screen.
