P a g e | 25

GXV3240 User Guide

PC Port

10/100/1000Mbps RJ-45 port connecting to PC.

LAN Port

10/100/1000Mbps RJ-45 port connecting to Ethernet.

Power Jack

12V DC Power connector port.

EXT Port

RJ11 connector port to connect the extension board GXP2200EXT.

Connecting the GXV3240

To setup your GXV3240, please follow the steps below:

1. Connect the handset and main phone case with the phone cord;

2. Connect the LAN port of the phone to the RJ-45 socket of a hub/switch or a router (LAN side of the

router) using the Ethernet cable;

3. Connect the 12V DC output plug to the power jack on the phone; plug the power adapter into an

electrical outlet. If PoE switch is used in step 2, this step could be skipped;

4. The LCD will display booting up or firmware upgrading information. Before continuing, please wait

for the main screen display to show up;

5. Using the web configuration interface or from the menu of the touch screen, you can further

configure network connection using static IP, DHCP and etc.

GXV3240 Extension Module (GXP2200EXT)

The GXV3240 uses GXP2200EXT as the extension module. The extension module is an ideal solution for

the busy enterprise environment looking to add the ability to receive and dispatch calls efficiently. Each

GXP2200EXT extension module has 20 programmable buttons, LEFT and RIGHT buttons, supporting 40

Multiple Purpose Keys to be configured. GXV3240 supports up to 4 extension modules, adding 160 fully

programmable phone extensions to the phone.

Table 5: GXP2200EXT Packaging

GXP2200EXT Board

GXP2200EXT Stand

RJ11-RJ11 Cable

Connector Plate

Screws

Quick Installation Guide
