X10SRL-F User’s Manual
Motherboard Features
CPU Single Intel
®
E5-2600/1600 Series processor in an
LGA2011 R3 socket.
Memory Eight (8) ECC/Non-ECC DDR4 RDIMM/LRDIMM at
1333/1600/1866/2133 MHz memory (1 DPC) up to 256GB
RDIMM or 512GB LRDIMM.
Dual-channel memory
DIMM sizes
RDIMM 1GB, 2 GB, 4GB, 8GB, 16GB, and
32GB
Chipset Intel
®
C612 Express
Expansion Slots One (1) PCI Express 2.0: 1 (x4 in x8)
Six (6) PCI Express 3.0: 2 (x8 in x16), 2 (x8), 1 (x8 or x4),
1 (x0 or x4)
Two (2) RJ-45 rear I/O panel connectors with Link and
Activity LEDs
I/O Devices SATA Connections
SATA 3.0 (6Gb/s)
Ten (10) SATA3 ports
•AHCI controller supports six (6)
SATA3 drives compatible with
RAID 0, 1, 5, 10.
•sSATA controller supports four
(4) SATA3 drives compatible
with RAID 0, 1, 5, 10.
•RAID array and volume(s) can-
not span across the two (AHCI
and sSATA) controllers.
SATA DOM Two (2) SATA DOM Ports (SATA 4/5)
USB Devices
Eight (8) USB 2.0 ports ( 2 rear, 6 via headers)
Four (4) USB 3.0 headers for USB 3.0 support (2 rear, 1
Type-A, 1 via header)
Serial (COM) Ports
Two (2) COM Ports (1 header, 1 rear)
Graphics Controller
AST 2400 Graphics Controller
Network One i210 Dual-Channel Gigabit (100/1000 MB/s)
Ethernet Contoller for LAN 1/LAN 2 ports
