Supermicro x10srl-f-o [41/129] Populating lrdimm memory modules

Chapter 2: Installation

2-15

Populating RDIMM Memory Modules

2 Slots per Channel RDIMM Population Congurations

Conguration

Number

POR Speed DIMM1 DIMM0

1 DDR4-2133,

1866, 1600

Empty Single-rank

2 DDR4-2133,

1866, 1600

Empty Dual-rank

3 DDR4-1866,

1600

Single-rank Single-rank

4 DDR4-1866,

1600

Single-rank Dual-rank

5 DDR4-1866,

1600

Dual-rank Dual-rank

Populating LRDIMM Memory Modules

2 Slots per Channel LRDIMM Population Congurations

Conguration

Number

POR Speed 1N or 2N DIMM1 DIMM0

1 DDR4-2133,

1866, 1600

2400 with BDX

1N Empty Quad-rank+

2 DDR4-2133,

1866, 1600

1N Quad-rank+ Quad-rank+
