Supermicro x10srl-f-o [3/129] Preface
![Supermicro x10srl-f-o [3/129] Preface](/views2/1190412/page3/bg3.png)
iii
Preface
Preface
This manual is written for system integrators, IT professionals, and
knowledgeable end users. It provides information for the installation and use of the
X10SRL-F motherboard.
About This Motherboard
The X10SRL-F supports a single Intel
®
E5-2600/1600 Series processor in
an LGA2011 R3 socket. With the Intel
®
C612 Express chipset built in, the X10SRL-
F motherboard supports Intel
®
Server Platform Services (Intel SPS), offering great
system enhancement to high performance storage platforms. Please refer to our
website (http://www.supermicro.com/products/) for processor and memory support
updates. This product is intended to be installed and serviced by professional
technicians.
Manual Organization
Chapter 1 describes the features, specications and performance of the mother-
board, and provides detailed information on the Intel
®
C612 Express chipset.
Chapter 2 provides hardware installation instructions. Read this chapter when in-
stalling the processor, memory modules and other hardware components into the
system. If you encounter any problems, see Chapter 3, which describes trouble-
shooting procedures for video, memory and system setup stored in the CMOS.
Chapter 4 includes an introduction to the BIOS, and provides detailed information
on running the CMOS Setup utility.
Appendix A provides BIOS Error Beep Codes.
Appendix B lists software program installation instructions.
Appendix C contains UEFI BIOS Recovery instructions.
Appendix D contains Dual Boot Block instructions.
