Appendix B: Power Supply Specications

Appendix B

SC732 Power Supply Specications

This appendix lists power supply specications for your chassis system.

SC732D4F-865B, SC732D4-865B, SC732D2-865B, SC732i-865B

865W

MFR Part # PWS-865-PQ

Rated AC Voltage

100 - 240V

50 - 60Hz

12 - 6 Amp

+5V standby 6.5 Amp

+12V 70 Amp

+5V 30 Amp

+3.3V 30 Amp

-12V 1 Amp

SC732D4F-500B, SC732D4-500B, SC732D2-500B, SC732i-500B

500W

MFR Part # PWS-502-PQ

Rated AC Voltage

100 - 240V

50 - 60Hz

12 - 6 Amp

+5V standby 6.5 Amp

+12V 69 Amp

+5V 30 Amp

+3.3V 305 Amp

-12V 1 Amp
