Tristar ra-2993 [4/64] Assembly instructions
![Tristar ra-2993 [4/64] Assembly instructions](/views2/1191845/page4/bg4.png)
6
7
3
1
2
4
5
4
• Make sure that the cord is not hanging over the edge of the table or
counter, does not touch any hot surfaces or is coming directly into
contact with the hot parts of the appliances. Do not place the appliance
underneath or close to curtains, window coverings etc.
• Make sure the cord does not touch the hot parts of the appliance.
• We advise to place a heat resistant coating between your table and the
appliance (this way you don't get burns on your table or table cloth).
• Be careful with oil and fat preparations because they might catch re by
overheating. Provide proper ventilation when using the appliance.
(*) Competent qualied electrician: after sales department of the producer or
importer or any person who is qualied, approved and competent to perform
this kind of repairs in order to avoid all danger. In any case you should return
the appliance to this electrician.
PARTS DESCRIPTION
1. Base
2. Reversible grill/baking plate
3. Temperature control switch
4. Control switch for rotating rollers/skewers
5. Drawers with rotating mechanism
6. Drip cup
7. 10 skewers/10 hot dog rollers
BEFORE THE FIRST USE
• Remove all packaging materials and any promotional labels or stickers
from the Tristar multifunctional stainless steel grill. Be sure all parts
(listed in the parts description) have been included before discarding
any packaging materials. You may want to keep the box and packing
materials for storage.
• Before using the grill for the rst time, remove any dust by wiping the
base and temperature control switch with a damp cloth. Thoroughly
clean both sides of the reversible plate, as well as the drip cup, drawers,
skewers and hot dog rollers. The grill plate, skewers, hot dog rollers, drip
cup and drawers can be hand washed or placed in the dishwasher for
cleaning.
ASSEMBLY INSTRUCTIONS
1. Place the base on a clean, at surface where you are intending to cook.
2. One end of the base has an opening provided for the drip cup. With the
metal spout tilted slightly forward, slide the drip cup into the base and
push in until the tab is locked (see gure A).
3. Insert the drawers by sliding the top rim of the back wall over the small
round tabs on either side of the opening. Push the drawers back until the
front is securely in place behind the round tabs (see gure B). Push the
drawers into the unit, lifting it over the retaining bar to secure. To remove
the drawers, allow the device to cool for 30 minutes. Remove all skewers,
then lift the drawer up over the round tabs, and pull it towards you.
4. The cooking plate has two sides.
• The side with a ribbed surface. This side is intended for grilling steaks,
hamburgers, chicken, seafood and vegetables.
• The side with the smooth surface is perfect for frying bacon, eggs,
pancakes, French toast and toasted sandwiches (see gure C).
