152
Index
A
AC adaptor ......................................................................12
Accompaniment..............................................................32
Accompaniment style .....................................................32
Accompaniment track.....................................................37
Accompaniment volume.................................................37
ACMP .............................................................................33
Auto Accompaniment .....................................................32
Auto Accompaniment on/off ....................................25, 33
Auto Accompaniment section...................................33, 34
Auto Fill..........................................................................34
B
BACK .............................................................................17
Backup ..........................................................................135
Bank ..........................................................................44, 56
BASS ........................................................................37, 96
Bass Hold......................................................................121
Batteries ..........................................................................12
Beat indicator..................................................................16
Break.............................................................................121
C
Chord ..................................................................16, 33, 38
Chord Fingerings ............................................................38
Chord Match .............................................................43, 94
CHORD1 ..................................................................37, 96
CHORD2 ..................................................................37, 96
Chorus.............................................................................48
Clear .................................................................91, 95, 104
Clock.............................................................................116
Control Change.............................................................107
Copy ...............................................................................64
D
Data dial..........................................................................20
DC IN 10-12V jack ........................................................12
Default ............................................................................20
Delete........................................................................21, 67
Demo song ......................................................................15
Digital effect ...........................................................46, 131
Direct Access ............................................................21, 24
DISK IN USE .................................................................58
Disk drive........................................................................58
Disk mode.......................................................................25
Display............................................................................16
DOC ....................................................................9, 68, 109
Drum Cancel ...................................................................99
Drum Kit.................................................................31, 128
DSP .................................................................................49
E
Easy Navigator .........................................................16, 18
Echo ........................................................................51, 133
Edit .................................................77, 86, 88, 91, 94, 102
Ending.............................................................................34
ESEQ ............................................................................109
EXIT ...............................................................................17
External.........................................................................116
F
FAST...................................................................16, 46, 49
Fingered1 ..................................................................38, 39
Fingered2 ..................................................................38, 40
Fingering...................................................................17, 38
Floppy disk .....................................................................58
Footswitch ..............................................................13, 121
Format.............................................................................60
Freeze .............................................................................55
Full Keyboard ...........................................................38, 40
Function ..........................................................17, 106, 118
Function tree ...................................................................22
G
GM (General MIDI) ...........................................9, 68, 109
H
Harmony ...................................................................16, 50
Harmony Volume ............................................................52
Harmony/Echo Type List ..............................................133
Headphone ......................................................................13
HOST SELECT ....................................................110, 111
I
Initial send ....................................................................117
Initialization..................................................................135
Insertion effect ........................................................50, 131
Internal..........................................................................116
Intro ................................................................................34
K
Keyboard ........................................................................29
Keyboard Percussion ......................................................31
L
Left .................................................................................29
Load ................................................................................62
Local Control ................................................................116
Loop recording ...............................................................97
Lower ............................................................................112
