Alarms and Warnings
118 3A1080F
Alarms and Warnings
NOTE: Do not use the fluid in the line that was dis-
pensed off ratio as it may not cure properly.
System Alarms
System alarms alert you of a problem and help prevent
off-ratio spraying. If an alarm occurs, operation stops
and the following occurs:
• Buzzer sounds (for E-2 only; see page 29 to set for
all alarms).
• Status bar on the EasyKey shows the alarm E-Code
with a description (see Table 17).
System Warnings
Table 17 lists the System Warning Codes. Warnings do
not stop operation or sound an alarm. They are saved in
the date/time stamped log, which can be viewed on a
PC, using the ProControl 1KS Web Interface (see man-
ual 313386).
To Reset Alarm and Restart
NOTE: When an alarm occurs be sure to determine the
E-Code before resetting it. See Table 17. If you forget
which E-Code occurred, use the Alarms Screen (page
24) to view the last 10 alarms, with date and time
stamps.
To reset alarms, see Table 18. Many alarms can be
cleared by simply pressing the Alarm Reset
key.
Table 17: System Alarm/Warning Codes
Code Description Details
E-1 Communication Error Alarm Page 119
E-2 Potlife Alarm Page 119
E-3 Ratio High Alarm Page 120
E-4 Ratio Low Alarm Page 121
E-5 Overdose A/B Dose Too Short
Alarm
Page 122
E-6 Overdose B/A Dose Too Short
Alarm
Page 122
E-7 Dose Time A Alarm Page 123
E-8 Dose Time B Alarm Page 123
E-9 Not used NA
E-10 Remote Stop Alarm Page 124
E-11 Purge Volume Alarm Page 124
E-12 CAN Network Communication Error
Alarm
Page 125
E-13 High Flow Alarm Page 126
E-14 Low Flow Alarm Page 126
E-15 System Idle Warning Page 126
E-16 Setup Change Warning Page 126
E-17 Power On Warning Page 126
E-18 Defaults Loaded Warning Page 126
E-19 I/O Alarm Page 127
E-20 Purge Initiate Alarm Page 128
E-21 Material Fill Alarm Page 128
E-22 Tank A Low Alarm Page 128
E-23 Tank B Low Alarm Page 128
E-24 Tank S Low Alarm Page 128
E-25 Auto Dump Complete Alarm Page 129
E-26 Color/Catalyst Purge Alarm Page 129
E-27 Color/Catalyst Fill Alarm Page 129
E-28 Mix Fill Push Complete Page 129
E-29 Tank C Low Alarm Page 129
E-30 Overdose C Alarm Page 129
E-31 Dose Time C Alarm Page 129
