Overview
3A1080F 13
Color Change
Valves (ACV) and
Color Change
Module (CCM)
An optional component. It is available as a color change valve stack for either low or high
pressure with up to 30 color change valves. Each stack includes one additional valve for
solvent to clean the fluid line between color changes.
Dual Fiber Optic
Cable (FO)
Used to communicate between the EasyKey and Fluid Station Control Box.
Fluid Station
Control Box Power
Supply Cable (PS)
Used to provide power to the Fluid Station Control Box.
Flow Control
Regulator
Assembly (FC)
Includes an air operated fluid pressure regulator, fluid pressure sensor, voltage to air
pressure transducer and circuit board. The function of this unit is to receive the flow ana-
log signal and drive (manage) the desired flow rate.
EasyKey (EK)
Used to set up, display, operate, and monitor the system. The EasyKey accepts 85-250
VAC, 50/60 Hz line power and converts that power to acceptable low voltage and optical
signals used by other system components.
Fluid Station
Control Box (ST)
Includes air control solenoids. Its control board manages all fluid functions.
Table 1: Component Descriptions (Continued)
Component Description
Содержание
- A1080f 1
- Operation 1
- Procontro 1
- Contents 2
- Equipment approvals 3
- Related manuals 3
- Models 4
- System configuration and part numbers 4
- Accessories 5
- Standard features 5
- Standard features accessories 5
- Warning 6
- Warnings 6
- Warning 7
- Changing materials 8
- Important two component material information 8
- Isocyanate conditions 8
- Keep components a and b separate 8
- Material self ignition 8
- Moisture sensitivity of isocyanates 8
- Glossary of terms 9
- Component identification and definition 12
- Overview 12
- Wall mount system components 14
- Display 16
- Easykey display and keypad 16
- Keypad 16
- Ac power switch 18
- Audible alarm 18
- Ethernet connection 18
- Graco web interface port 18
- I s power 18
- Run mode screens 19
- Splash screen 19
- 3a1080f 20
- Run mode screens 20
- Run screens map 20
- Status screen 21
- Flow control calibration 22
- Flow rate range 22
- Flow set point 22
- Manual override menu 22
- Manual override screen 22
- Global flow control data copy 23
- Reset solvent screen 23
- Reset total screen 23
- Totals screen 23
- Alarms screen 24
- Level control screen 24
- Setup mode 25
- Password screen 26
- Set up home screen 26
- System configuration screens 28
- Configure screen 1 29
- Configure screen 2 29
- Configure screen 3 30
- Configure screen 4 30
- Configure screen 5 30
- Configure screen 6 31
- Option screen 1 32
- Option screens 32
- Verification screen 32
- Option screen 2 33
- Advanced setup screens 34
- Advanced setup screens map 34
- For a map of the advanced setup screens detailed screen descriptions follow 34
- Note see 34
- Advanced setup screen 1 35
- Advanced setup screen 2 36
- Advanced setup screen 3 36
- Advanced setup screen 4 37
- Advanced setup screen 5 37
- Advanced setup screen 6 38
- Advanced setup screen 7 38
- Advanced setup screen 10 39
- Advanced setup screen 8 39
- Advanced setup screen 9 39
- Recipe setup screens 40
- Recipe setup screen 1 41
- Recipe setup screen 2 41
- Recipe setup screen 3 42
- Recipe setup screen 4 42
- Recipe setup screen 5 43
- Recipe setup screen 6 43
- Recipe setup screen 7 44
- Recipe 0 screen 1 45
- Recipe 0 screen 2 45
- Recipe 0 screens 45
- Recipe 0 screen 3 46
- Recipe 0 screen 4 46
- Calibration screen 47
- Procontrol integration specifics 49
- System setup for automatic operation 49
- Discrete i o vs network communications 50
- Status verification of automatic operation 50
- Discrete i o 51
- Digital inputs 52
- 255766 discrete i o board 53
- A1080f 53 53
- Procontrol integration specifics 53
- Analog inputs 54
- Digital outputs 54
- Automation flow charts 55
- Start mix mode process 55
- Start mix mode process flow chart 55
- Table 5 and table 6 55
- Mixing mode process 56
- Mixing mode process flow chart 56
- Table 5 and table 6 56
- Purge mode process 57
- Purge mode process flow chart 57
- Table 5 and table 6 57
- Color change mode process 58
- Color change mode process flow chart 58
- Table 5 and table 6 58
- Alarm processing 59
- Alarm processing flow chart 59
- Table 5 table 6 and table 7 and table 8 59
- Table 7 procontrol 1ks low word active alarms modbus register 40010 62
- Table 8 procontrol 1ks high word active alarms modbus register 40010 62
- Automation 24 vdc sourcing input diagram 63
- Plc input sinking 63
- Plc output sourcing 63
- Procontrol 1ks easykey digital input 63
- Procontrol 1ks easykey digital out 63
- Procontrol easykey digital output plc input sourcing 63
- Color change process 66
- Modbus and i o data 66
- Purge process 66
- Start mix process 66
- Stop mix process 66
- Color change 69
- Gun trigger input 69
- Start mixing 69
- Stop mixing 69
- Typical plc interaction with procontrol 1ks 69
- Alarm monitoring reset discrete i o 70
- Integration timing charts 70
- Job_complete input 70
- Integration control recipe change x to y 71
- Integration control recipe change x to y external color change 72
- Integration control y purge 73
- Integration control y fill 74
- Integration control y purge and fill 75
- Integration control mix sequences 76
- Integration control alarm processing 77
- Cutaway of 249849 flow control module 78
- Cutaway of 24h989 flow control module 78
- Flow control components 78
- Flow control description 78
- Flow control is an optional feature which incorporates an intrinsically safe regulator control module with the pro control 1ks automatic system flow control precisely regulates the flow of material to a manual or automatic air spray gun to help ensure adequate coverage and avoid sags or runs in the finish coat 78
- Flow control module 78
- Flow control uses the existing flow meters in a wall mounted fluid station or a robomix fluid station there is no flow meter in the mixed material line 78
- H989 flow control module 78
- Integrated flow control 78
- Note flow control cannot be selected with dynamic dosing it is not for use with air assisted or airless spray guns 78
- Note for best results place the supplied pressure sensor as close to the remote fluid regulator as possible 78
- The 249849 flow control module includes an air operated fluid pressure regulator fluid pressure sensor voltage to air pressure valve and circuit board see manual 3a2097 the function of this unit is to receive the flow analog signal and drive manage the desired flow rate 78
- The 24h989 flow control module is for use with a user supplied remotely mounted air operated fluid pressure regulator the module includes a remote fluid pressure sensor and connecting cable voltage to air pressure valve and circuit board see manual 3a2097 the function of this unit is to receive the flow analog signal and drive manage the desired flow rate 78
- Flow control operation 79
- Fluid and air pressure requirements 79
- 3a1080f 80
- Integrated flow control 80
- Procontrol 1ks flow control schematic diagram 249849 module 80
- Procontrol 1ks flow control schematic diagram 24h989 module 80
- Flow control operating process example 81
- Operating ranges 81
- Step 1 flow set point input signal 81
- Step 2 pressure loop 81
- Step 3 flow loop 81
- 3a1080f 82
- Integrated flow control 82
- Procontrol 1ks flow control pressure loop and flow loop 249849 module 82
- Procontrol 1ks flow control pressure loop and flow loop 24h989 module 82
- Flow control setup 83
- Flow control startup 83
- One point learning 84
- One point learning example 84
- Table 13 example spray sequence 84
- Flow control calibration 85
- Mix calibration 85
- Global fc data copy 86
- Continuous learning 87
- Setting ki and kp 87
- Pressure flow control mode 88
- Flow control troubleshooting 89
- Problem flow command does not produce fluid output 89
- Mix manifold valve settings 91
- Operation modes 91
- Recipe color change 91
- Solvent push 91
- Standby 91
- System operation 91
- Start up 92
- Overnight shutdown 94
- Pressure relief procedure 94
- Service shutdown 94
- Shutdown 94
- Single color systems 94
- Systems with color change and dump valves 95
- Fluid solenoids 96
- J1 j12 j3 j9 j14 96
- Purging 98
- Purging mixed material 98
- Purging fluid supply system 99
- Purging using recipe 0 99
- Solvent push feature 101
- Meter calibration 102
- Color change 104
- Color change procedures 104
- Color change sequences 104
- Multiple color systems 104
- Single color systems 104
- Catalyst fill 105
- Catalyst purge dump 105
- Chop cycle 105
- Color fill 105
- Color purge dump 105
- Final purge 105
- First purge 105
- Procontrol 1ks recipe change chart 1 x to y 107
- Procontrol 1ks recipe change chart 2 x to y 108
- Procontrol 1ks recipe fill chart 3 0 to y 109
- Procontrol 1ks recipe fill chart 4 0 to y 110
- Procontrol 1ks recipe fill chart 5 0 to y 111
- Procontrol 1ks recipe fill chart 6 0 to y 112
- Procontrol 1ks recipe purge chart 7 x to 0 113
- Procontrol 1ks recipe purge chart 8 x to 0 114
- Procontrol 1ks recipe purge chart 9 0 to 0 115
- Procontrol 1ks recipe purge chart 10 0 to 0 116
- Alarms and warnings 118
- System alarms 118
- System warnings 118
- To reset alarm and restart 118
- Alarm troubleshooting 119
- 3a1080f 130
- Control air 130
- Purge air 130
- Schematic diagrams 130
- System pneumatic schematic 130
- A1080f 131 131
- Non hazardous area 131
- Note the electrical schematic illustrates all possible wiring expansions in a procontrol 1ks system some compo nents shown are not included with all systems 131
- Schematic diagrams 131
- System electrical schematic 131
- 3a1080f 132
- Booth control board 132
- Flow control board 132
- Fluid press sens 132
- Hazardous area 132
- I s meters 132
- Note the electrical schematic illustrates all possible wiring expansions in a procontrol 1ks system some compo nents shown are not included with all systems 132
- Schematic diagrams 132
- System electrical schematic 132
- Tecno v p 132
- A1080f 133 133
- Easykey electrical schematic 133
- Schematic diagrams 133
- 3a1080f 134
- Cc dose 134
- Flow rate cc min 134
- Fluid hydraulic oil viscosity 65 centipoise ratio tolerance 5 valve setting 1 5 turns open standard setting a and b feed pressure 300 psig 134
- Meter performance data g3000 on a and b 134
- Note maximum system flow is 3800 cc min 134
- Test conditions 134
- A1080f 135 135
- Cc dose 135
- Flow rate cc min 135
- Fluid hydraulic oil viscosity 65 centipoise ratio tolerance 5 valve setting 1 5 turns open standard setting a and b feed pressure 300 psig 135
- Meter performance data g3000 on a coriolis on b 135
- Note maximum system flow is 3800 cc min 135
- Test conditions 135
- Technical data 136
- For patent information see www graco com patents 138
- For the latest information about graco products visit www graco com 138
- Graco headquarters minneapolis international offices belgium china japan korea 138
- Graco inc and subsidiaries p o box 1441 minneapolis mn 55440 1441 usa copyright 2009 graco inc all graco manufacturing locations are registered to iso 9001 www graco com revision f march 2016 138
- Graco information 138
- Graco standard warranty 138
- To place an order contact your graco distributor or call to identify the nearest distributor phone 612 623 6921 or toll free 1 800 328 0211 fax 612 378 3505 138
Похожие устройства
- Graco ProControl 1KS Руководство по подключению
- Graco ProControl 1KS Технические характеристики
- Graco ProDispense Инструкция по эксплуатации
- Graco ProDispense Брошюра
- Graco ProDispense Сертификат
- Graco EcoQuip 2 EQm Инструкция по эксплуатации
- Graco EcoQuip 2 EQm Брошюра
- Graco EcoQuip 2 EQs Инструкция по эксплуатации
- Graco EcoQuip 2 EQs Брошюра
- Graco EcoQuip 2 EQs Elite Инструкция по эксплуатации
- Graco EcoQuip 2 EQs Elite Брошюра
- Graco EcoQuip 2 EQs2 Twinline Инструкция по эксплуатации
- Graco EcoQuip 2 EQs2 Twinline Брошюра
- Graco Manzel GBL 7500 24K466 Инструкция по эксплуатации
- Graco Manzel GBL 7500 24K466 Технические характеристики
- Graco Manzel GBL 7500 24K466 Сертификат
- Graco Manzel GBL 7500 24J391 Инструкция по эксплуатации
- Graco Manzel GBL 7500 24J391 Технические характеристики
- Graco Manzel GBL 7500 24J392 Инструкция по эксплуатации
- Graco Manzel GBL 7500 24J392 Технические характеристики
