ProControl Integration Specifics
3A1080F 61
NOTE: Shaded cells relate to the flow charts on pages 55-59.
Table 6: ProControl 1KS Digital Outputs (Modbus Register 40041)
Bit Digital Output Binary Name Details
0 000000000000000
1 Purge_CC_Active “1” indicates Purge or Color Change is in progress
1 00000000000000
10Mix_Active “1” indicates Mix is in progress
2 0000000000000
100Mix_Ready “1” indicates No Alarms and OK to Mix
3 0000000000001000CC_Fill_Active “1” indicates the Fill portion of a Color Change is in
progress
4 0000000000010000FCalActive “1” indicates the Flow Control Calibrate routine is in
progress
5 0000000000100000Flow_Rate_Alarm “1” indicates the Flow Rate Alarm/Warning is
active
6 0000000001000000Special_1 “1” indicates the Special_1 output is on (monitor
only)
7 0000000010000000Special_2 “1” indicates the Special_2 output is on (monitor
only)
8 0000000100000000Special_3 “1” indicates the Special_3 output is on (monitor
only)
9 0000001000000000Special_4 “1” indicates the Special_4 output is on (monitor
only)
10 0000010000000000GFB _1_Copy “1” indicates the output for GFB 1 is on
11 0000100000000000GFB _2_Copy “1” indicates the output for GFB 2 is on
12 0 0 0
1000000000000Alarm_General “1” indicates a General Alarm is in process. (If Mix-
_Active is still High, then a Warning only.) See the
Modbus charts in the Graco Gateway manual
312785 for details on type.
13 0010000000000000Alarm_Potlife “1” indicates a Potlife Alarm is in process.
14 0100000000000000AFS _1_Copy “1” indicates the AFS 1 input to the Fluid Panel is
on
15 1000000000000000AFS _2_Copy “1” indicates the AFS 2 input to the Fluid Panel is
on
