Related Manuals
3A1163A 3
Related Manuals
Component Manuals in English
Equipment Approvals
Equipment approvals appear on the following labels
which are attached to the Fluid Station Control Box and
EasyKey
™
. See FIG. 1 on page 4 for label locations.
Manual Description
3A1080 ProControl 1KS Operation
3A1164 ProControl 1KS Repair-Parts
312782 Dispense Valve
312783 Color Change Valve Stacks
312787 Color Change Module Kit
312784 Gun Flush Box Kits
310745 Gun Air Shutoff Kit
312786 Dump Valve and Third Purge Valve Kits
312785 Network Communication Kits
308778 G3000/G3000HR/G250/G250HR Flow
Meter
313599 Coriolis Flow Meter
313212 Gun Flush Box Integration Kit
313290 Floor Stand Kit
313542 Beacon Kit
313386 Basic Web Interface/Advanced Web
Interface
406800 15V825 Discrete I/O Board Kit
SERIES NO. MFG. YR.
PART NO.
AMPS
VOLTS
85-250 ~
2 AMPS MAX
POWER REQUIREMENTS
GRACO INC.
P.O. Box 1441
Minneapolis, MN
55440 U.S.A.
II (2) G
[Ex ia] IIA
FM08ATEX0072
Intrinsically safe connections
for Class I, Div 1, Group D
Ta = -20°C to 50°C
Install per 289833
CUS
277869
50/60 Hz
ProControl 1KS
Um: 250 V
.7 7 100
MAX AIR WPR
MPa bar PSI
FLUID PANEL
ProControl
PART NO. SERIES SERIAL
GRACO INC.
P.O. Box 1441
Minneapolis, MN
55440 U.S.A.
Intrinsically safe equipment
for Class I, Div 1, Group D, T3
Ta = -20°C to 50°C
Install per 289833
FM08ATEX0073
II 2 G
Ex ia IIA T3
.7 7 100
MAX AIR WPR
MPa bar PSI
1.31
13.1 190
MAX FLUID WPR
MPa bar PSI
PART NO. SERIES
Read Instruction Manual
Warning: Substitution of components
may impair intrinsic safety.
SERIAL
ProControl 1KS
Electronic Proportioner
MAX TEMP 50°C (122°F)
Intrinsically Safe (IS) System. Install
per IS Control Drawing No. 289833.
EasyKey Interface IS Associated
Apparatus for use in non hazardous
location, with IS Connection to Smart
Fluid Plate IS
Apparatus for use in:
Class I, Division 1, Group D T3 C
Hazardous Locations
Intrinsically safe
equipment for Class I,
Div 1, Group D, T3
Ta = -20°C to 50°C
CUS
FM08ATEX0074
II 2 G
Ex ia IIA T3
GRACO INC.
P.O. Box 1441
Minneapolis, MN
55440 U.S.A.
MFG. YR.
ATEX Certificate is listed here
ATEX Certificate is listed here
ATEX Certificate is listed here
EasyKey Label
Fluid Station Control Box Label
EasyKey and Fluid Station Control Box Label
