Installation
3A3101D 13
Outlet Pressure
psi (MPa, bar)
3/8 in. Fluid Plunger Pumps
Minimum Gas Pressure
psi (MPa, bar)
1.25 in. Air Motor 1.75 in. Air Motor 2 in. Air Motor
0 (0, 0) 50 (0.34, 3.4) 50 (0.34, 3.4) 50 (0.34, 3.4)
150 (1, 10.3) 63 (0.44, 4.4) 50 (0.34, 3.4) 50 (0.34, 3.4)
300 (2.1, 20.7) 77 (0.53, 5.3) 50 (0.34, 3.4) 50 (0.34, 3.4)
450 (3.1, 31) 90 (0.62, 6.2) 46 (0.32, 3.2) 50 (0.34, 3.4)
600 (4.1, 41.4) 104 (0.72, 7.2) 53 (0.36, 3.6) 41 (0.28, 2.8)
750 (5.2, 51.7) 117 (0.81, 8.1) 60 (0.41, 4.1) 46 (0.32, 3.2)
900 (6.2, 62.1) 131 (0.90, 9.0) 67 (0.46, 4.6) 51 (0.35, 3.5)
1050 (7.2, 72.4) 144 (0.99, 9.9) 74 (0.51, 5.1) 56 (0.39, 3.9)
1200 (8.3, 82.7) 158 (1.09, 10.9) 80 (0.55, 5.5) 62 (0.42, 4.2)
1350 (9.3, 93.1) 171 (1.18, 11.8) 87 (0.60, 6.0) 67 (0.46, 4.6)
1500 (10.3, 103.4) 185 (1.27, 12.7) 94 (0.65, 6.5) 72 (0.50, 5.0)
1650 (11.4, 113.8) 198 (1.37, 13.7) 101 (0.70, 7.0) 77 (0.53, 5.3)
1800 (12.4, 124.1) - 108 (0.74, 7.4) 83 (0.57, 5.7)
1950 (13.4, 134.4) - 115 (0.79, 7.9) 88 (0.61, 6.1)
2100 (14.5, 144.8) - 122 (0.84, 8.4) 93 (0.64, 6.4)
2250 (15.5, 155.1) - 129 (0.89, 8.9) 99 (0.68, 6.8)
2400 (16.5, 165.5) - 136 (0.93, 9.3) 104 (0.72, 7.2)
2550 (17.6, 175.8) - 142 (0.98, 9.8) 109 (0.75, 7.5)
2700 (18.6, 186.2) - 149 (1.03, 10.3) 114 (0.79, 7.9)
2850 (19.7, 196.5) - 156 (1.08, 10.8) 120 (0.82, 8.2)
3000 (20.7, 206.8) - 163 (1.12, 11.2) 125 (0.86, 8.6)
3150 (21.7, 217.2) - 170 (1.17, 11.7) 130 (0.90, 9.0)
3300 (22.8, 227.5) - 177 (1.22, 12.2) 135 (0.93, 9.3)
3450 (23.8, 237.9) - 184 (1.27, 12.7) 141 (0.97, 9.7)
3600 (24.8, 248.2) - 191 (1.31, 13.1) 146 (1.01, 10.1)
3750 (25.9, 258.6) - 198 (1.36, 13.6) 151 (1.04, 10.4)
3900 (26.9, 268.9) - - 157 (1.08, 10.8)
4050 (27.9, 279.2) - - 162 (1.12, 11.2)
4200 (29.0, 289.6) - - 167 (1.15, 11.5)
4350 (30.0, 299.9) - - 172 (1.19, 11.9)
4500 (31.0, 310.3) - - 178 (1.22, 12.2)
4650 (32.1, 320.6) - - 183 (1.26, 12.6)
4800 (33.1, 330.9) - - 188 (1.30, 13.0)
4950 (34.1, 341.3) - - 193 (1.33, 13.3)
5100 (35.2, 351.6) - - 199 (1.37, 13.7)
