Graco Python 1/8" [20/56] Baseline chemical dosage settings
Operation
20 3A3101D
Baseline Chemical Dosage Settings
See Stroke Adjustment, page 19, for stroke adjust settings. See Performance Charts, starting on page 44, for
maximum flows at any given pressure.
CPM
1/8 in. Fluid Plunger Pumps 3/16 in. Fluid Plunger Pumps
GPD (LPD) GPD (LPD)
Full Stroke 3/4 Stroke 1/2 Stroke 1/4 Stroke Full Stroke 3/4 Stroke 1/2 Stroke 1/4 Stroke
5
0.3 (1.1) 0.2 (0.8) 0.1 (0.5) 0.1 (0.3) 0.6 (2.4) 0.5 (1.8) 0.3 (1.2) 0.2 (0.6)
10
0.6 (2.2) 0.4 (1.6) 0.3 (1.1) 0.1 (0.5) 1.3 (4.9) 1.0 (3.7) 0.6 (2.4) 0.3 (1.2)
15
0.9 (3.3) 0.6 (2.4) 0.4 (1.6) 0.2 (0.8) 1.9 (7.3) 1.5 (5.5) 1.0 (3.7) 0.5 (1.8)
20
1.1 (4.3) 0.9 (3.3) 0.6 (2.2) 0.3 (1.1) 2.6 (9.8) 1.9 (7.3) 1.3 (4.9) 0.6 (2.4)
25
1.4 (5.4) 1.1 (4.1) 0.7 (2.7) 0.4 (1.4) 3.2 (12.2) 2.4 (9.2) 1.6 (6.1) 0.8 (3.1)
30
1.7 (6.5) 1.3 (4.9) 0.9 (3.3) 0.4 (1.6) 3.9 (14.7) 2.9 (11) 1.9 (7.3) 1.0 (3.7)
35
2.0 (7.6) 1.5 (5.7) 1.0 (3.8) 0.5 (1.9) 4.5 (17.1) 3.4 (12.8) 2.3 (8.6) 1.1 (4.3)
40
2.3 (8.7) 1.7 (6.5) 1.1 (4.3) 0.6 (2.2) 5.2 (19.5) 3.9 (14.7) 2.6 (9.8) 1.3 (4.9)
45
2.6 (9.8) 1.9 (7.3) 1.3 (4.9) 0.6 (2.4) 5.8 (22.0) 4.4 (16.5) 2.9 (11.0) 1.5 (5.5)
50
2.9 (10.9) 2.2 (8.1) 1.4 (5.4) 0.7 (2.7) 6.5 (24.4) 4.8 (18.3) 3.2 (12.2) 1.6 (6.1)
55
3.2 (11.9) 2.4 (9.0) 1.6 (6.0) 0.8 (3.0) 7.1 (26.9) 5.3 (20.2) 3.6 (13.4) 1.8 (6.7)
60
3.4 (13.0) 2.6 (9.8) 1.7 (6.5) 0.9 (3.3) 7.7 (29.3) 5.8 (22.0) 3.9 (14.7) 1.9 (7.3)
CPM
1/4 in. Fluid Plunger Pumps 3/8 in. Fluid Plunger Pumps
GPD (LPD) GPD (LPD)
Full Stroke 3/4 Stroke 1/2 Stroke 1/4 Stroke Full Stroke 3/4 Stroke 1/2 Stroke 1/4 Stroke
5
1.4 (5.3) 1.1 (4.0) 0.7 (2.7) 0.4 (1.3) 3.2 (12.2) 2.4 (9.2) 1.6 (6.1) 0.8 (3.1)
10
2.8 (10.7) 2.1 (8.0) 1.4 (5.3) 0.7 (2.7) 6.5 (24.5) 4.9 (18.4) 3.2 (12.2) 1.6 (6.1)
15
4.2 (16.0) 3.2 (12.0) 2.1 (8.0) 1.1 (4.0) 9.7 (36.7) 7.3 (27.6) 4.9 (18.4) 2.4 (9.2)
20
5.6 (21.3) 4.2 (16.0) 2.8 (10.7) 1.4 (5.3) 12.9 (49.0) 9.7 (36.7) 6.5 (24.5) 3.2 (12.2)
25
7.0 (26.6) 5.3 (20.0) 3.5 (13.3) 1.8 (6.7) 16.2 (61.2) 12.1 (45.9) 8.1 (30.6) 4.0 (15.3)
30
8.4 (32.0) 6.3 (24.0) 4.2 (16.0) 2.1 (8.0) 19.4 (73.5) 14.6 (55.1) 9.7 (36.7) 4.9 (18.4)
35
9.9 (37.3) 7.4 (28.0) 4.9 (18.6) 2.5 (9.3) 22.7 (85.7) 17.0 (64.3) 11.3 (42.9) 5.7 (21.4)
40
11.3 (42.6) 8.4 (32.0) 5.6 (21.3) 2.8 (10.7) 25.9 (98.0) 19.4 (73.5) 12.9 (49.0) 6.5 (24.5)
45
12.7 (48.0) 9.5 (36.0) 6.3 (24.0) 3.2 (12.0) 29.1 (110.2) 21.8 (82.7) 14.6 (55.1) 7.3 (27.6)
50
14.1 (53.3) 10.6 (40.0) 7.0 (26.6) 3.5 (13.3) 32.4 (122.5) 24.3 (91.9) 16.2 (61.2) 8.1 (30.6)
55
15.5 (58.6) 11.6 (44.0) 7.7 (29.3) 3.9 (14.7) 35.6 (134.7) 26.7 (101.1) 17.8 (67.4) 8.9 (33.7)
60
16.9 (63.9) 12.7 (48.0) 8.4 (32.0) 4.2 (16.0) 38.8 (147.0) 29.1 (110.2) 19.4 (73.5) 9.7 (36.7)
