Graco Python 1/8" [3/56] Note see the configuration number matrix page 4 to find the plunger and air motor size for your unit
Models
3A3101D 3
Models
NOTE: See the Configuration Number Matrix, page 4, to find the plunger and air motor size for your unit.
Plunger Size Air Motor Size
Maximum Working Pressure
psi (MPa, bar)
Maximum Pneumatic Inlet Pressure
psi (MPa, bar)
1/8 in.
1-1/4 in.
12,000 (82.7, 827) 170 (1.17, 11.7)
3/16 in. 6500 (44.8, 448)
200 (1.40, 14.0)
1/4 in. 3500 (24.1, 241)
3/8 in. 1500 (10.3, 103)
1/2 in. 875 (6.0, 60)
5/8 in. 500 (3.4, 34)
3/4 in. 400 (2.8, 28)
1/8 in.
1-3/4 in.
12,000 (82.7, 827) 87 (0.60, 6.0)
3/16 in. 12,000 (82.7, 827) 163 (1.12, 11.2)
1/4 in. 7000 (48.3, 483)
200 (1.40, 14.0)
3/8 in. 3000 (20.6, 206)
1/2 in. 1750 (12.1, 121)
5/8 in. 1000 (6.9, 69)
3/4 in. 800 (5.5, 55)
1/8 in.
2 in.
12,000 (82.7, 827) 66 (0.46, 4.6)
3/16 in. 12,000 (82.7, 827) 125 (0.86, 8.6)
1/4 in. 9500 (65.5, 655) 168 (1.16, 11.6)
3/8 in. 4000 (27.6, 276)
200 (1.40, 14.0)
1/2 in. 2250 (15.5, 155)
5/8 in. 1500 (10.3, 103)
3/4 in. 1000 (6.9, 69)
