3A3101D 37

Python Pneumatic Pump Parts List

 Replacement Danger and Warning labels, tags, and

cards are available at no cost.

* Not included with PCI-xxx-xxH configurations.

Ref. Part Description Qty.

1 B32163 Air motor housing, for 1/2” and

smaller fluid plungers

1

B32164 Air motor housing, for 5/8” and

larger fluid plungers

1

2 B32165 Air piston stop, for 1.25” air pis-

ton

1

B32166 Air piston stop, for 1.75” and

2.0” air pistons

1

3See

Table 1,

pg 38

Fluid plunger wiper, included

with fluid plunger spring (ref. 4)

1

4See

Table 1,

pg 38

Fluid plunger spring 1

5See

Table 2,

pg 38

Fluid plunger 1

6 B32172 Air piston, 1.25” 1

B32173 Air piston, 1.75” 1

B32174 Air piston, 2.0” 1

7 B32034 O-ring packing, 1.25”, included

with air piston (ref. 6)

1

B32035 O-ring packing, 1.75”, included

with air piston (ref. 6)

1

B32036 O-ring packing, 2.0”, included

with air piston (ref. 6)

1

8 B32205 Air piston cylinder, 1.25” 1

B32206 Air piston cylinder, 1.75” 1

B32207 Air piston cylinder, 2.00” 1

9 B32163 Retaining ring, included with air

motor housing (ref. 1)

1

10 B32175 Set screw, included with air

motor housing (ref. 1)

3

11 B32176 O-ring packing, for 1/2” and

smaller fluid plungers; included

with dust shield (ref. 12)

1

B32177 O-ring packing, for 5/8” and

larger fluid plungers; included

with dust shield (ref. 12)

1

12 B32178 Dust shield, for 1/2” and smaller

fluid plungers

1

B32179 Dust shield, for 5/8” and larger

fluid plungers

1

13 See

Table 3,

pg 38

Fluid cylinder 1

14 See

Table 4,

pg 38

Plunger bearings, included with

packing (ref. 15)

2

15 See

Table 4,

pg 38

Packing 1

16 See

Table 5,

pg 39

Packing nut 1

17 See

Table 6,

pg 39

Inlet valve check 1

18 See

Table 7,

pg 39

Outlet valve check 1

19 B32191 Priming bleed valve housing,

standard pressure (1/4”, 3/8”,

1/2”, 5/8”, & 3/4” plungers)

1

B32250 Priming bleed valve housing,

high pressure (1/8” & 3/16”

plungers)

1

20* B32192 Priming bleed valve; included

with priming bleed valve hous-

ing (ref. 19)

1

21 B32192 Pump stroke adjuster 1

22 B32069 Spool timing valve, see pg 41 1

25 17G319 Warning label, hanging 1

27 17G320 Warning label, adhesive 1

33 -- Cap plug 2
