Parts
38 3A3101D
Table 1: Fluid Plunger Springs (ref. 4), including Plunger Wipers (ref. 3)
Table 2: Fluid Plungers (ref. 5)
Table 3: Fluid Cylinders (ref. 16)
Table 4: Packing Stacks (ref. 15), including Plunger Bearings (ref. 14)
Ref
Part Numbers by Fluid Plunger Size Diameter
Qty.1/8 in. 3/16 in. 1/4 in. 3/8 in. 1/2 in. 5/8 in. 3/4 in.
4 B32167 B32167 B32167 B32168 B32169 B32170 B32171
1
Ref
Part Numbers by Fluid Plunger Size Diameter
Qty.1/8 in. 3/16 in. 1/4 in. 3/8 in. 1/2 in. 5/8 in. 3/4 in.
17-4 Stainless Steel Fluid Plungers
5 B32066 B32067 B32068 B32135 B32136 B32137 B32138
1
Chromex-Coated Fluid Plungers
5 B32139 B32140 B32141 B32142 B32143 B32144 B32145
1
Ceramic-Coated Fluid Plungers
5 B32241 B32242 B32243 B32244 B32245 B32246 B32247
1
Ref
Part Numbers by Fluid Plunger Size Diameter
Qty.1/8 in. 3/16 in. 1/4 in. 3/8 in. 1/2 in. 5/8 in. 3/4 in.
13 B32180 B32181 B32182 B32183 B32184 B32185 B32180
1
Ref
Part Numbers by Fluid Plunger Size Diameter
Qty.1/8 in. 3/16 in. 1/4 in. 3/8 in. 1/2 in. 5/8 in. 3/4 in.
FKM
15 B32115 B32119 B32094 B32098 B32102 B32123 B32127
1
FKMETP
15 B32116 B32120 B32095 B32099 B32103 B32124 B32128
1
HNBR
15 B32117 B32121 B32096 B32100 B32104 B32125 B32129
1
FFKM
15 B32118 B32122 B32097 B32101 B32105 B32126 B32130
1
AFLAS
15 B32033 B32041 B32042 B32043 B32044 B32085 B32086
1
