Parts
3A3101D 39
Table 5: Packing Nuts (ref. 16)
Table 6: Inlet Valve Check (ref. 17)
Table 7: Outlet Valve Check (ref. 18)
Ref
Part Numbers by Fluid Plunger Size Diameter
Qty.1/8 in. 3/16 in. 1/4 in. 3/8 in. 1/2 in. 5/8 in. 3/4 in.
16 B32187 B32187 B32187 B32188 B32203 B32190 B32190
1
Ref
Part Numbers by Fluid Plunger Size Diameter
Qty.1/8 in. 3/16 in. 1/4 in. 3/8 in. 1/2 in. 5/8 in. 3/4 in.
FKM
17 B32226 B32226 B32216 B32024 B32024 B32024 B32024
1
FKMETP
17 B32228 B32228 B32218 B32026 B32026 B32026 B32026
1
HNBR
17 B32230 B32230 B32220 B32113 B32113 B32113 B32113
1
FFKM
17 B32232 B32232 B32222 B32028 B32028 B32028 B32028
1
Ref
Part Numbers by Fluid Plunger Size Diameter
Qty.1/8 in. 3/16 in. 1/4 in. 3/8 in. 1/2 in. 5/8 in. 3/4 in.
FKM
18 B32227 B32227 B32217 B32025 B32025 B32025 B32025
1
FKMETP
18 B32229 B32229 B32219 B32027 B32027 B32027 B32027
1
HNBR
18 B32231 B32231 B32221 B32114 B32114 B32114 B32114
1
FFKM
18 B32233 B32233 B32223 B32029 B32029 B32029 B32029
1
