Graco Python 1/8" [42/56] Additional kits accessories
Kits and Accessories
42 3A3101D
Kits and Accessories
Additional Kits & Accessories
Part No. Description
B32045 225-750 PSI Pressure Relief Valve Kit
(Adjustable)
B32046 750-1500 PSI Pressure Relief Valve Kit
(Adjustable)
B32047 1500-2250 PSI Pressure Relief Valve Kit
(Adjustable)
B32048 2250-3000 PSI Pressure Relief Valve Kit
(Adjustable)
B32049 3000-4000 PSI Pressure Relief Valve Kit
(Adjustable)
B32050 4000-5000 PSI Pressure Relief Valve Kit
(Adjustable)
B32051 5000-6000 PSI Pressure Relief Valve Kit
(Adjustable)
B32088 SST Calibration Column Kit
B32089 SST Manifold Assembly Kit
B32157 316 SST Ball Valve Kit, 3/4” NPT(F)
B32158 Fluid Filter 6000 PSI
B32159 Fluid Filter 10000 PSI
B32160 Float Switch
B32162 1/4" NPT(F) X 1/4" NPT(F) Check Kit
B32038 FKM Large (3/8” - 3/4”) Inlet and Outlet
Check Valve Repair Kit (includes a spring
and piston o-rings)
B32039 FKM ETP Large (3/8” - 3/4”) Inlet and Out-
let Check Valve Repair Kit (includes a
spring and piston o-rings)
B32040 FFKM Large (3/8” - 3/4”) Inlet and Outlet
Check Valve Repair Kit (includes a spring
and piston o-rings)
B32111 HNBR Large (3/8” - 3/4”) Inlet and Outlet
Check Valve Repair Kit (includes a spring
and piston o-rings)
B32224 FKM Small (1/8” - 1/4”) Inlet and Outlet
Check Valve Repair Kit (includes a spring
and piston o-rings)
B32225 FKM ETP Small (1/8” - 1/4”) Inlet and Outlet
Check Valve Repair Kit (includes a spring
and piston o-rings)
B32235 FFKM Small (1/8” - 1/4”) Inlet and Outlet
Check Valve Repair Kit (includes a spring
and piston o-rings)
B32234 HNBR Small (1/8” - 1/4”) Inlet and Outlet
Check Valve Repair Kit (includes a spring
and piston o-rings)
B32240 HF4 to 1/4” NPT(F) Adapter; 10,000 psi
(1/8” - 3/16” plungers)
