Moxa Managed Ethernet Switches Featured Functions
3-27
Port Events Warning e-mail is sent when...
Power-Fail When actual PD power consumption exceeds related PD power limit setting.
PD-Failure When the switch cannot receive a PD response after the defined period.
PoE Relay Warning Events Settings
Relay Warning Event Types can be divided into two basic groups: Power-Fail and PD-Failure.
Port Events Warning e-mail is sent when...
Power-Fail When actual PD power consumption exceeds related PD power limit settings.
PD-Failure When the switch cannot receive a PD response after the defined period.
