Moxa EDS-408A-1M2S-SC-T [77/109] X re authentication

Moxa Managed Ethernet Switches Featured Functions

3-65

Radius Server

Setting Description Factory Default

IP address or domain

name

The IP address or domain name of the RADIUS server local host

Server Port

Setting Description Factory Default

Numerical The UDP port of the RADIUS server 1812

Shared Key

Setting Description Factory Default

alphanumeric (Max. of

40 characters)

A key to be shared between the external RADIUS server and

Moxa switch. Both ends must be configured to use the same

key.

None

Re-Auth

Setting Description Factory Default

Enable/Disable Select enable to require re-authentication of the client after a

preset time period of no activity has elapsed.

Disable

Re-Auth Period

Setting Description Factory Default

Numerical

(60 to 65535 sec.)

Specify how frequently the end stations need to reenter

usernames and passwords in order to stay connected.

3600

802.1X

Setting Description Factory Default

Enable/Disable Checkmark the checkbox under the 802.1X column to enable

IEEE 802.1X for one or more ports. All end stations must enter

usernames and passwords before access to these ports is

allowed.

Disable

802.1X Re-Authentication

The Moxa switch can force connected devices to be re-authorized manually.

802.1X Re-Authentication

Setting Description Factory Default

Enable/Disable Enables or disables 802.1X Re-Authentication Disable
