Moxa Managed Ethernet Switches Featured Functions

3-59

Type 1

Traffic Rate Limiting Settings

Control Mode Description Factory Default

Normal Set the max. ingress rate limit for different packet types Normal

Port Disable When the ingress multicast and broadcast packets exceed the

ingress rate limit, the port will be disabled for a certain period.

During this period, all packets from this port will be discarded.

Ingress Rate Limit - Normal

Policy Description Factory Default

Limit All Select the ingress rate limit for different

packet types from the following options:

Not Limited, 128K, 256K, 512K, 1M, 2M,

4M, 8M

Limit Broadcast 8M

Limit Broadcast, Multicast, Flooded Unicast

Limit Broadcast, Multicast

Limit Broadcast

Ingress Rate Limit – Port Disable

Setting Description Factory Default

Port disable duration

(1~65535 seconds)

When the ingress multicast and broadcast packets exceed the

ingress rate limit, the port will be disabled for this period of

time. During this time, all packets from this port will be

discarded.

30 second

Ingress (fps) Select the ingress rate (fps) limit for all packets from the

following options: Not Limited, 4464, 7441, 14881, 22322,

37203, 52084, 74405

Not Limited
