Moxa EDS-510E-3GTXSFP-T Руководство пользователя Англ. онлайн
Moxa Managed Ethernet Switch
(UI_2.0_FW_4.x) User’s Manual
Edition 3.2, September 2016
www.moxa.com/product
© 2016 Moxa Inc. All rights reserved.
Models covered by this user's manual (only applies to products
using firmware versions 4.x; for firmware versions 5.x, please
refer to the Moxa Managed Ethernet Switch (UI_2.0_FW_5.x)
User’s Manual):
EDS-510E, EDS-518E, EDS-G508E, EDS-G512E, EDS-G516E,
EDS-G512E-8PoE, IKS-6726A, IKS-6728A, IKS-6728A-8PoE,
IKS-G6524A, IKS-G6824A, ICS-G7526A, ICS-G7826A, ICS-G7528A,
ICS-G7828A, ICS-G7748A, ICS-G7848A, ICS-G7750A, ICS-G7850A,
ICS-G7752A, ICS-G7852A Series
