Managed Ethernet Switch (UI_2.0_FW_4.x) Featured Functions

3-5

Network

Network configuration allows users to configure both IPv4 and IPv6 parameters for management access over

the network. The Moxa switch supports both IPv4 and IPv6, and can be managed through either of these

address types.

IP Settings

The IPv4 settings include the switch’s IP address and subnet mask, as well as the IP address of the default

gateway. In addition, input cells are provided for the IP addresses of a 1st and 2nd DNS server.

The IPv6 settings include two distinct address types—Link-Local Unicast addresses and Global Unicast

addresses. A Link-Local address makes the switch accessible over IPv6 for all devices attached to the same

local subnet. To connect to a larger network with multiple segments, the switch must be configured with a

Global Unicast address.

Get IP From

Setting Description Factory Default

DHCP

The Moxa switch’s IP address will be assigned automatically by

the network’s DHCP server.

DHCP

BOOTP

The Moxa switch’s IP address will be assigned automatically by

the network’s BootP server.

Manual The Moxa switch’s IP address must be set manually.

IP Address

Setting Description Factory Default

IP address for the Moxa

switch

Assigns the Moxa switch’s IP address on a TCP/IP network. 192.168.127.253

Subnet Mask

Setting Description Factory Default

Subnet mask for the

Moxa switch

Identifies the type of network the Moxa

switch is connected to

(e.g., 255.255.0.0 for a Class B network, or 255.255.255.0 for

a Class C network).

24(255.255.255.0)

Default Gateway

Setting Description Factory Default

IP address for gateway

Specifies the IP address of the router that connects

the LAN to

an outside network.

None
