Moxa EDS-510E-3GTXSFP-T [41/105] Event type

Managed Ethernet Switch (UI_2.0_FW_4.x) Featured Functions

3-28

exceptions occur. The PoE Ethernet switch supports different methods for warning engineers automatically,

including SNMP trap, email, and relay output. It also supports two digital inputs to integrate sensors into your

system to automate alarms using email and relay output. The PoE warning event settings are on the System

Event Settings page.

Warning Type

Action Description

Trap The EDS E series will send a notification to the trap server when

event is triggered.

E-Mail The EDS E series will send a notification to the email server defined

in Email Settings.

Syslog The EDS E series will record a syslog to a syslog server defined in

Syslog Server Settings.

Relay1 The EDS E series supports digital inputs to integrate sensors. When

an event is triggered, the device will automatically activate an

alarm through the relay output.

Event Type

Port Events Description

PoE PD power on Power is being output to the PD.

PoE PD power off The PoE power output is cut off.

PoE over current When the current of the port exceeds the following limits:

802.3 af: 350 mA

802.3 at: 600 mA

High Power: 720 mA

Force: 600 mA

PoE PD Failure Check When the switch does not receive a PD response after the defined

period.

Over-measured Power Limit When the total PD power consumption exceeds the total measured

power limit.

PoE FETBad When the MOSFET of the port is out of order (please contact Moxa

for technical service)

PoE over Temperature Please check the temperature of the environment. If you cannot

keep the temperature under 75°C, please contact Moxa for

technical service.

PoE VEE Uvlo - VEE (PoE input voltage)

under Voltage Lockout

The voltage of the power supply has dropped below 44 VDC.

Adjust

the voltage between 46 and 57 VDC to eliminate this issue.

Over Allocated Power Limit When the total PD power consumption exceeds the total a

llocated

power.
