- 12 -
NOTE
You must enable the Turbo Ring function first
before using the
DIP switch to activate the Master and Coupler functions.
NOTE
If you do not enable any of the
EDS-G512E-8PoE series
switches
to be the Ring Master, the Turbo Ring protocol will automatically
choose the
EDS-G512E-8PoE series with the smallest MAC
address range to be the Ring Master. If you accidentally enable
more than one
EDS-G512E-8PoE series to be the Ring Master,
these
EDS-G512E-8PoE series switches will auto-negotiate to
determine which one will be the Ring Master.
LED Indicators
The front panel of the Moxa EDS-G512E-8PoE series contains several LED
indicators. The function of each LED is described in the following table:
LED
Color
Status
Description
STATE
Green
On
The system passed the self-diagnosis test
on boot-up and is ready to run.
Blinking
1.
The switch is under reset progress (1
time/s).
2. Detect ABC-02-USB connect to the
switch (1 time/2s).
Red On
The system failed self-diagnosis on
boot-up.
• RAM Test Fail / System Info. Read Fail
/ Switch Initial Fail / PTP PHY Error.
(+ Green MSTR lit on : HW FAIL)
• FW Checksum Fail / Uncompress Fail.
(+ Green Coupler lit on: SW FAIL)
FAULT
Red On
1. The signal contact is open.
2. ABC Loading/Saving Fail.
3.
The port being disabled because of the
ingress multicast and broadcast
packets exceed the ingress rate limit.
4. Incorrect loop connection in a single
switch.
5. Invalid Ring port connection.
PWR1 Amber
On
Power is being supplied to the main
module’s power input PWR1.
Off
Power is not being supplied to the main
module’s power input PWR1.
PWR2 Amber
On
Power is being supplied to the main
module’s power input PWR2.
Off
Power is not being supplied to the main
module’s power input PWR2.
