1. Introduction

The UPort 1100 Series of USB-to-serial converters provides an easy way to add COM ports to your computer.

The UPort 1110 provides one RS-232 port; the UPort 1130 and UPort 1130I each provide one RS-422/RS-485

port; the UPort 1150 and UPort 1150I each provide one RS-232/422/485 port. As a plug-and-play USB device,

the converters are perfect for mobile, instrumentation, and point-of-sale applications.

The UPort 1100 series includes the following models:

UPort 1110: 1-port RS-232 USB-to-serial converter.

UPort 1130: 1-port RS-422/485 USB-to-serial converter.

UPort 1130I: 1-port RS-422/485 USB-to-serial converter with isolation protection.

UPort 1150: 1-port RS-232/422/485 USB-to-serial converter.

UPort 1150I: 1-port RS-232/422/485 USB-to-serial converter with isolation protection.

The following topics are covered in this chapter:



Overview

 ARDC (Automatic Recovery Data Communication)



Package Checklist



Product Features



Product Specifications



LED Indicators

 Adjustable Pull High/Low, Terminator Resistors for the RS-485 Port
