Installing the Industio CP-132 Series board

Step 1: Power off the PC.

WARNING

Make sure your system is switched off before you start installing any

board. If you don’t, you may risk

damaging your system and the board.

Step 2: Remove the PC’s cover.

Step 3: Remove the slot cover bracket if there is any.

Step 4: Plug the Industio CP-132 Series control board firmly into a free 32-bit PCI slot.

Step 5: Fasten the holding screw to fix the control board in place.

Step 6: Replace the system cover.

Step 7: Power on the PC and the BIOS will automatically set the IRQ and I/O address.

NOTE

Each board must occupy one unique IRQ and two 8

-byte I/O addresses, which are assigned

automatically by the PCI BIOS

. However, you can select a free IRQ number manually via the PC’s BIOS

setup for the PCI slot, but normally this method is not available for the I/O address. The possible IRQ numbers

are 2, 3, 4, 5, 7, 10, 11

, 12, and 15. The possible I/O addresses are from 0x0000 to 0xFFFF.

Step 8: Proceed with the software installation detailed in the next chapter, “Software Installation”.
