CP-132 Series Software Installation

3-5

NOTE

Once the board and the driver are installed and the driver restarts successfully, you can start to develop

applications with the

PComm library (See “Serial Programming Tools” chapter) or the Microsoft Win32 API.

You can also execute any ready

-made applications, such as PComm utility Terminal emulator (See “Serial

Programming Tools” chapter) or HyperTerminal to transmit/receive data, as well as Remote Access Service to

provide dial

-up networking capabilities.

Configuring Board and Port

If you already have installed the driver and want to re-configure the ports, please follow this procedure.

1. In the [Control Panel], click on the [Network] icon and select the [Adapters] tab.

2. Select “MOXA Smartio/Industio Family Adapter” in “Network Adapters”.

3. Click on the [Properties] button to open the “MOXA Smartio/Industio Configuration Panel” dialog

box. Please see steps 8-9 in the previous section, “Installing Driver”, for more details.

In this configuration panel, you may:

• Click [Property] to enter “Property” dialog box to configure the selected board with the correct “COM

Number”, “Rx FIFO Trigger” and “Tx FIFO Size”. Please see steps 8 to 9 in the previous section,

“Installing Driver”, for more details.

• Click [Add] to add one more board that is not yet configured in the system. Please see steps 6 to 9 in

the previous section, “Installing Driver”, for more details.
