Universal PCI Board Pin Assignments
5-6
DB25 (Female): RS-422
Pin Signal Pin Signal
1 --- 14 ---
2 TxD1-(A) 15 RxD1-(A)
3
GND1
16
---
4 --- 17 ---
5 TxD1+(B) 18 RxD1+(B)
6 --- 19 ---
7 --- 20 ---
8 --- 21 TxD0-(A)
9 RxD0-(A) 22 GND0
10 --- 23 ---
11 --- 24 TxD0+(B)
12 RxD0+(B) 25 ---
13 --- --- ---
DB25 (Female): RS-485 (4-wire)
Pin Signal Pin Signal
1 --- 14 ---
2 TxD1-(A) 15 RxD1-(A)
3 GND1 16 ---
4 --- 17 ---
5 TxD1+(B) 18 RxD1+(B)
6 --- 19 ---
7 --- 20 ---
8 --- 21 TxD0-(A)
9 RxD0-(A) 22 GND0
10 --- 23 ---
11 --- 24 TxD0+(B)
12
RxD0+(B)
25
---
13 --- --- ---
DB25 (Female): RS-485 (2-wire)
Pin Signal Pin Signal
1
---
14
---
2 --- 15 Data1-(A)
3 GND1 16 ---
4 --- 17 ---
5 --- 18 Data1+(B)
6 --- 19 ---
7 --- 20 ---
8 --- 21 ---
9 Data0-(A) 22 GND0
10 --- 23 ---
11 --- 24 ---
12 Data0+(B) 25 ---
13 --- --- ---
