Universal PCI Board Pin Assignments
5-9
DB62 (Female): RS-232
Pin Signal Pin Signal Pin Signal
1 TxD0 22 RxD0 43 CTS0
2 DTR0 23 DSR0 44 RTS0
3
RxD1
24
DCD0
45
GND
4 DSR1 25 TxD1 46 CTS1
5 DCD1 26 DTR1 47 RTS1
6 TxD2 27 RxD2 48 CTS2
7 DTR2 28 DSR2 49 RTS2
8 RxD3 29 DCD2 50 GND
9 DSR3 30 TxD3 51 CTS3
10 DCD3 31 DTR3 52 RTS3
11 RxD4 32 GND 53 CTS4
12 DSR4 33 TxD4 54 RTS4
13 DCD4 34 DTR4 55 GND
14 TxD5 35 RxD5 56 CTS5
15 DTR5 36 DSR5 57 RTS5
16 RxD6 37 DCD5 58 GND
17 DSR6 38 TxD6 59 CTS6
18 DCD6 39 DTR6 60 RTS6
19 RxD7 40 GND 61 CTS7
20 DSR7 41 TxD7 62 RTS7
21 DCD7 42 DTR7 --- ---
DB62 (Female): RS-422, RS-485 (4-wire)
Pin Signal Pin Signal Pin Signal
1 RxD0+(B) 22 TxD0+(B) 43 ---
2 RxD0-(A) 23 --- 44 ---
3 TxD1+(B) 24 TxD0-(A) 45 GND
4
---
25
RxD1+(B)
46
---
5 TxD1-(A) 26 RxD1-(A) 47 ---
6 RxD2+(B) 27 TxD2+(B) 48 ---
7 RxD2-(A) 28 --- 49 ---
8 TxD3+(B) 29 TxD2-(A) 50 GND
9 --- 30 RxD3+(B) 51 ---
10 TxD3-(A) 31 RxD3-(A) 52 ---
11 TxD4+(B) 32 GND 53 ---
12 --- 33 RxD4+(B) 54 ---
13 TxD4-(A) 34 RxD4-(A) 55 GND
14 RxD5+(B) 35 TxD5+(B) 56 ---
15 RxD5-(A) 36 --- 57 ---
16 TxD6+(B) 37 TxD5-(A) 58 GND
17 --- 38 RxD6+(B) 59 ---
18 TxD6-(A) 39 RxD6-(A) 60 ---
19 TxD7+(B) 40 GND 61 ---
20 --- 41 RxD7+(B) 62 ---
21 TxD7-(A) 42 RxD7-(A) --- ---
