Universal PCI Board Pin Assignments
5-10
DB62 (Female): RS-485 (2-wire)
Pin Signal Pin Signal Pin Signal
1 Data0+(B) 22 --- 43 ---
2 Data0-(A) 23 --- 44 ---
3
---
24
---
45
GND
4 --- 25 Data1+(B) 46 ---
5 --- 26 Data1-(A) 47 ---
6 Data2+(B) 27 --- 48 ---
7 Data2-(A) 28 --- 49 ---
8 --- 29 --- 50 GND
9 --- 30 Data3+(B) 51 ---
10 --- 31 Data3-(A) 52 ---
11 --- 32 GND 53 ---
12 --- 33 Data4+(B) 54 ---
13 --- 34 Data4-(A) 55 GND
14 Data5+(B) 35 --- 56 ---
15 Data5-(A) 36 --- 57 ---
16 --- 37 --- 58 GND
17 --- 38 Data6+(B) 59 ---
18 --- 39 Data6-(A) 60 ---
19 --- 40 GND 61 ---
20 --- 41 Data7+(B) 62 ---
21 --- 42 Data7-(A) --- ---
