V2201 Series Hardware BIOS Setup
4-20
C:\>
V2201>V2201S10.exe
Option:
-bios –all -nv
Please do not remove the AC power!
Insyde H20FFT (Flash Firmware Tool) Version (SEG) 100.00.07.20
Copyright(c) 2012 – 2014, Insyde Software Corp. All Rights
Reserved.
Initializing
Current BIOS Model name: V2201
New BIOS Model name: V2201
Current BIOS version: V1.00S10
New BIOS version: V1.00S10
Updating Block at FFFFF000
6. When the upgrade is finished, the computer automatically reboots. You may check the BIOS version on the
Main page of the BIOS setup utility.
BIOS Version
Project Name
V
1.00S10
V
2201
0%
25%
50%
75%
100%
100%
