DA-683 XPE User's Manual System Recovery
Recovery Environment
The environment includes a DA-683-XPE embedded computer and a bootable USB disk with the recovery
programs and system image file.
Hardware
The hardware used includes a PC, a DA-683-XPE computer and a USB disk with the recovery programs. (Note:
The USB disk should be at least 2GB.).
USB Ports
DA-683-XPE
USB DISK
(R
ecovery data included)
Recovery Procedure
Step 1: Install XPE Disk Recovery
Insert the software CD (in your package) into your computer and find XPeRecovery.msi in the recovery
folder. Double-click XPeRecovery.msi to start the setup process and click Next.
4-2
