MD-224 Hardware Manual Display UART Commands
C-11
MCC Command Syntax and Functionality Details and Values
Reset "r": 07 FF 4D 43 43 02 24 B4 72 D9
Increase "+": 07 FF 4D 43 43 02 24 B4 2B 20
Decrease "-": 07 FF 4D 43 43 02 24 B4 2D 1E
Green Level for Selected
Color
Syntax: 07 FF 4D 43 43 03 23 B5 xx yy zz
Function Examples:
Example "50": 07 FF 4D 43 43 03 23 B5 35 30 E5
Query "?": 07 FF 4D 43 43 02 24 B5 3F 0B
Reset "R": 07 FF 4D 43 43 02 24 B5 52 F8
Reset "r": 07 FF 4D 43 43 02 24 B5 72 D8
Increase "+": 07 FF 4D 43 43 02 24 B5 2B 1F
Decrease "-": 07 FF 4D 43 43 02 24 B5 2D 1D
Where xx = "0" to "6"
Where yy = "0" to "F"
Where zz = Calculated Checksum
Max Range: "0" "0" to "6" "4"
Default: "6" "4"（100）
Blue Level for Selected Color Syntax: 07 FF 4D 43 43 03 23 B6 xx yy zz
Function Examples:
Example "50": 07 FF 4D 43 43 03 23 B6 35 30 E4
Query "?": 07 FF 4D 43 43 02 24 B6 3F 0A
Reset "R": 07 FF 4D 43 43 02 24 B6 52 F7
Reset "r": 07 FF 4D 43 43 02 24 B6 72 D7
Increase "+": 07 FF 4D 43 43 02 24 B6 2B 1E
Decrease "-": 07 FF 4D 43 43 02 24 B6 2D 1C
Where xx = "0" to "6"
Where yy = "0" to "F"
Where zz = Calculated Checksum
Max Range: "0" "0" to "6" "4"
Default: "6" "4"（100）
Graphic Horizontal Resolution
Query
Send only: 07 FF 4D 43 43 01 25 B7 48 Available response status:
"xxx" = where xxx is a 3-digit HEX
number indicating resolution.
Example:
"0780" = 1920 in decimal
Graphic Vertical Resolution
Query
Send only: 07 FF 4D 43 43 01 25 B8 47 Available response status:
"xxx" = where xxx is a 3-digit HEX
number indicating resolution.
Example:
"0480" = 1200 in decimal
Graphic Horizontal Sync.
Frequency
Send only: 07 FF 4D 43 43 01 25 B9 46 Available response status:
"xxx" = where xxx is a 3-digit HEX
number indicating frequency in
units of 100Hz.
Example:
"2A3" = 675 or 67.5 kHz decimal
Graphic Vertical Sync.
Frequency
Send only: 07 FF 4D 43 43 01 25 BA 45 Available response status:
"xxx" = where xxx is a 3-digit HEX
number indicating frequency in
units of 0.1Hz + 1 character
indicating field mode as:
"i" = Interlaced
"p" = Progressive
Example:
"258p" = 600 (60 Hz), progressive
fields
Set Address RS/Serial Syntax: 07 FF 4D 43 43 02 24 BB xx zz
Function Example:
Example “9”: 07 FF 4D 43 43 02 24 BB 39 0B
Query “?”: 07 FF 4D 43 43 02 24 BB 3F 05
Reset “R”: 07 FF 4D 43 43 02 24 BB 52 F2
Reset “r”: 07 FF 4D 43 43 02 24 BB 72 D2
Where xx = “0” to “F”
Where zz = Calculated Checksum
Default and reset value are “0”
Test Pattern Syntax: 07 FF 4D 43 43 02 24 CD xx zz
Function Examples:
Where xx = “0” to “1”
Where zz = Calculated Checksum
