MD-224 Hardware Manual Introduction

1-2

Overview

The MD-224 Series is the 24-inch version of our marine display series. Designed for durably reliable service as

an ECDIS (Electronic Chart Display and Information System) display component, the MD-224 Series has a 16:9

aspect ratio, alongside full range dimming and optional optical bonding, making the displays well-suited not

only for ECDIS applications, but for a variety of other bridge applications, as well.

The MD-224 Series features both AC and DC power inputs, and may be conveniently installed on any bridge,

without the need for extra hardware.

Moxa’s marine displays are compliant with the most important industrial marine standards, such as IEC 60945,

DNV, and IACS-E10, giving strong assurance of their suitability for marine applications.

Ordering Information

Available Models

MD-224X: 24-inch display, 16:9 aspect ratio, full HD (1920x1080), LED backlighting, RS-232 & RS-422/485

serial ports, dual-power supply (AC/DC)

MD-224Z: 24-inch display, 16:9 aspect ratio, full HD (1920x1080), projected-capacitive touch panel, LED

backlighting, RS-232 & RS-422/485 serial ports, dual-power supply (AC/DC)

Optional Accessories (can be purchased separately)

• Desktop mounting kit

• Panel mounting clamps

• VESA mounting kit

Package Checklist

Each model is shipped with the following items:

• MD-224 display

• VGA cable

• DVI-D cable

• 2-pin terminal block x 1

• 5-pin terminal block x 2

• Documentation and software CD

• Quick installation guide (printed)

• Warranty card

NOTE

Please notify your sales representative if any of the above items are missing or damaged.
