C. LED Test

The LED Test function verifies if the I/M Readiness LED indicator

lamps are functioning properly.

1) Use the SCROLL button to select LED Test from the Tool

Self-test menu, and then press the ENTER/Exit button.

2) In the LED Self-test menu, use the SCROLL button to select

one or more LED lamps to check. The LED should turn on or

off according to the selected commands.

Figure 3.10

3) When completed, press the ENTER/Exit button to exit.

Update Mode

This function allows you to update the scan tool software and DTC

library through a computer.

 To update your scan tool, you need the following items.

AutoLink



AL319

A PC or laptop with USB ports

A USB cable

1) Download the programs to be updated to your computer.

2) Run the MaxiLinkII Tool Kit in your computer. (Figure 3.11)

3) Connect the scan tool to your computer through the USB cable

provided.

LED Self-test 1/4

RED LED ON

YELLOW LED ON

GREEN LED ON

Previous Menu
