4) View live PIDs on the screen. Use the SCROLL button for more

PIDs if additional information is available on more than one page.

Figure 4.12

 The number “x” to the right of the screen indicates sequence

of the highlighted item.

5) Press the ENTER/Exit button to return to previous menu.

6) Select Previous Menu from the Read Codes screen, and press

ENTER/Exit button to return to previous menu

4.4 Viewing Freeze Frame Data

Freeze Frame Data allows the technician to view the vehicle‟s

operating parameters at the moment a DTC (Diagnostic Trouble Code)

is detected. For example, the parameters may include engine speed

(RPM), engine coolant temperature (ECT), or vehicle speed sensor

…………………View Data 1/3.

Complete Data Set

Unit of Measure

Previous Menu

Live Data 6

DTC_CNT 0

FUELSYS1 0L

FUELSYS2 --

LOAD_PCT (%) 0.0

ETC(℃) -40

SHRTFT1 (%) 99.2
