Figure 4.16

5) If the vehicle supports readiness test of “This Drive Cycle”, a

screen of the following displays:

Figure 4.17

6) The LEDs and audio tone corresponding to different monitor

status will be activated as below.

LED Light

Audio Tone

Beep Interval

Green LED

Two long beeps

2 minutes

Yellow LED

short, long, short beep

2 minutes

Red LED

Four short beeps

2 minutes

7) Use the SCROLL button for more PIDs if additional information

is available on more than one page.

8) Press the ENTER/Exit button to return to Diagnostic Menu.

…………Since DTCs Cleared 1

MIL Status OFF

Misfire Monitor OK

Fuel System Mon OK

Comp. Component OK

Catalyst Mon INC

Htd Catalyst N/A

…………..This Drive Cycle 1.

MIL Status OFF

Misfire Monitor OK

Fuel System Mon N/A

Comp. Component OK

Catalyst Mon INC

Htd Catalyst N/A
