ioLogik E1500 Series Active OPC Server Utility
5-8
Auto-save Updated Configuration: Once you activate auto-save, the Active OPC will automatically save
the configuration when access synchronizes.
System Log Settings: Enable or disable the Active OPC Server system log function. A Log file of all Logging
information will be created.
Launch DCOM Configuration: Launch the Windows DCOM configuration utility.
Register OPC as Service: Force Active OPC Server to run as a Windows system service.
Register OPC Server: Register the DCOM components to a Windows system. After Active OPC Server is
installed, it will automatically configure the DCOM.
Unregister OPC Server: Cancel the registration of DCOM components from the Windows system.
Sort
The Sort menu allows the server list in the navigation panel to be sorted by connection and type (model).
Quick Links
Quick links are provided for sorting the server list and importing/exporting configurations.
Sort by connection
Import configuration
Sort by server type
Export configuration
