ioLogik E1500 Series Modbus/TCP Default Address Mappings
A-5
Reference Address Data Type Description
DI Channel
40257 0x0100 1 bit CH0 DI Counter Operate Status 0: Stop 1: Start(R/W)
40258 0x0101 1 bit CH1 DI Counter Operate Status 0: Stop 1: Start(R/W)
40259 0x0102 1 bit CH2 DI Counter Operate Status 0: Stop 1: Start(R/W)
40260 0x0103 1 bit CH3 DI Counter Operate Status 0: Stop 1: Start(R/W)
40261 0x0104 1 bit CH4 DI Counter Operate Status 0: Stop 1: Start(R/W)
40262
0x0105
1 bit
CH5 DI Counter Operate Status 0: Stop 1: Start(R/W)
40263 0x0106 1 bit CH6 DI Counter Operate Status 0: Stop 1: Start(R/W)
40264 0x0107 1 bit CH7 DI Counter Operate Status 0: Stop 1: Start(R/W)
40265 0x0108 1 bit CH8 DI Counter Operate Status 0: Stop 1: Start(R/W)
40267 0x0109 1 bit CH9 DI Counter Operate Status 0: Stop 1: Start(R/W)
40268 0x010A 1 bit CH10 DI Counter Operate Status 0: Stop 1: Start(R/W)
40269 0x010B 1 bit CH11 DI Counter Operate Status 0: Stop 1: Start(R/W)
40273 0x0110 1 bit CH0 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
40274 0x0111 1 bit CH1 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
40275 0x0112 1 bit CH2 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
40276 0x0113 1 bit CH3 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
40277 0x0114 1 bit CH4 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
40278 0x0115 1 bit CH5 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
40279 0x0116 1 bit CH6 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
40280 0x0117 1 bit CH7 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
40281 0x0118 1 bit CH8 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
40282 0x0119 1 bit CH9 DI Clear Count Value
