D. Pinouts
Pin assignment of Terminal Blocks
ioLogik E1510
(Bottom) (TOP)
1
N.C. 1
N.C.
2
N.C. 2
N.C.
3
+12 (Out) 3
+12 (Out)
4
+0 (Out) 4
+0 (Out)
5
DI0 + 5
DI6 +
6
DI0 - 6
DI6 -
7
DI1 + 7
DI7 +
8
DI1 - 8
DI7 -
9
DI2 + 9
DI8 +
10
DI2 - 10
DI8 -
11
DI3 + 11
DI9 +
12
DI3 - 12
DI9 -
13
DI4 + 13
DI10 +
14
DI4 - 14
DI10 -
16
DI5 + 15
DI11 +
17
DI5 - 16
DI11 -
ioLogik E1512
(Bottom) (TOP)
1
N.C. 1
N.C.
2
N.C. 2
N.C.
3
+12 (Out)
3
COM0
4
+0 (Out) 4
N.C.
5
DI0 + 5
DIO0
6
DI0 - 6
DIO1
7
DI1 + 7
GND0
8
DI1 -
9
DI2 + 8
COM1
10
DI2 - 9
N.C.
11
DI3 + 10
DIO2
12
DI3 - 11
DIO3
13
N.C. 12
GND1
14
N.C. 13
N.C.
15
N.C. 14
N.C.
16
N.C. 15
N.C.
16
N.C.
NOTE
“N.C.” stands for “no connection.”
