ioLogik E1500 Series Modbus/TCP Default Address Mappings
A-7
Reference Address Data Type Description
00262 0x0105 1 bit CH5 DI Counter Operate Status 0: Stop 1: Start(R/W)
00263 0x0106 1 bit CH6 DI Counter Operate Status 0: Stop 1: Start(R/W)
00264 0x0107 1 bit CH7 DI Counter Operate Status 0: Stop 1: Start(R/W)
00273 0x0110 1 bit CH0 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00274 0x0111 1 bit CH1 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00275 0x0112 1 bit CH2 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00276 0x0113 1 bit CH3 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00277 0x0114 1 bit CH4 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00278 0x0115 1 bit CH5 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00279 0x0116 1 bit CH6 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00280 0x0117 1 bit CH7 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
1xxxx Read only Coils (Support function 2)
Dynamic Modbus 1xxxx Read Coils (Support function 2)
Reference Address Data Type Description
DI Channel
10001 0x0000 1 bit
CH0 DI Value，0=OFF，1=ON (Read only)
10002 0x0001 1 bit
CH1 DI Value
，
0=OFF
，
1=ON (Read only)
10003 0x0002 1 bit
CH2 DI Value，0=OFF，1=ON (Read only)
10004 0x0003 1 bit
CH3 DI Value，0=OFF，1=ON (Read only)
10005 0x0004 1 bit
CH4 DI Value，0=OFF，1=ON (Read only)
10006 0x0005 1 bit
CH5 DI Value，0=OFF，1=ON (Read only)
10007 0x0006 1 bit
CH6 DI Value，0=OFF，1=ON (Read only)
10008 0x0007 1 bit
CH7 DI Value，0=OFF，1=ON (Read only)
