ioPAC 5500 Hardware ioPAC 5500 Hardware Introduction
3-5
Product Hardware Specifications
Product Selection Guide
Model Name Description
ioPAC 5542-C-T RTU controller, 8AIs, 8 DIs, 8DIOs, C/C++, -40 to 75°C operating
temperature
ioPAC 5542-HSPA-C-T RTU controller with HSPA module, 8AIs, 8 DIs, 8DIOs, C/C++, -30 to 75°C
operating temperature
ioPAC 5542-IEC-T RTU controller, 8AIs, 8 DIs, 8DIOs, IEC 61131-3, -40 to 75°C operating
temperature
ioPAC 5542-HSPA-IEC-T RTU controller with HSPA module, 8AIs, 8 DIs, 8DIOs, IEC 61131-3, -30 to
75°C operating temperature
NOTE
Conformal coating available on request.
Product Specifications
Computer
Main CPU:
32-bit ARM9 192 MHz CPU
I/O CPU:
32-bit ARM Cortex M4 80 MHz CPU
OS:
Linux
Clock:
Real-time clock with battery backup
Memory:
• SDRAM: 64 MB
• Flash: 32 MB
• SRAM: 256
KB (battery backup lasts for 1 week)
• microSD™ Slot: Up to 32 GB (SD 2.0 compatible)
Note: For units operating in extreme temperatures, industrial grade, wide
-temperature microSD cards are
required.
Cellular (for the ioPAC 5542-HSPA Series)
Network:
• Quad
-band GSM/GPRS/EDGE 850/900/1800/1900 MHz
• Five
-band UMTS/HSPA+ 800/850/AWS/1900/2100 MHz
Internet:
HSPA:
• Up to 5.76 Mbps upload speed
• Up to 14.4 Mbps download speed
UMTS: Up to 384 kbps upload/download speed
EDGE Class 12: Up to 237 kbps uplo
ad/download speed
GPPRS Class 12: Up to 85.6 kbps upload/download speed
SMS:
Point-to-Point Text/PDU mode
SIM Control Voltage:
3/1.8 V
Ethernet Interface
LAN:
2 x 10/100 Mbps, 2 MACs (IPs), RJ45
Protection:
1.5 kV magnetic isolation
Serial Communication
Interface:
• 2 RS
-232/422/485 ports, software selectable (DB9 male)
• 1 RS
-232 debug port (4-pin connector)
Serial Line Protection:
15 kV ESD for all signals
