ioPAC 5500 Hardware Introduction

1-2

Overview

The ioPAC 5500 standalone controllers use an ARM9 based industrial-grade CPU for the main system, with ARM

Cortex™ M4 based CPUs for the I/O channels. The USB bus between the controller CPU and module CPUs

transmits data at up to 200 Mbps, and the dual CPU architecture supports a 2 kHz analog input sampling rate

and millisecond timestamps. The ioPAC 5500 supports C/C++ and IEC 61131-3 programming, rail-level surge

and ESD protection, a -40 to 75°C (-30 to 75°C for HSPA models) operating temperature range, UL/cUL Class

1 Division 2 certification, two 10/100 Mbps Ethernet ports with two MACs (Port Trunking ready), and two

3-in-1 serial ports. With Moxa's Active OPC Server and DA-Center, the ioPAC 5500 series provides a

comprehensive solution for data acquisition and control applications in harsh environments.

Package Checklist

ioPAC 5500

The ioPAC 5500 ships with the following items:

• ioPAC 5500 controller

• Serial console cable (C/C++ models only)

• Documentation and software CD

Optional Accessories (can be purchased separately)

• WK-51-01: Wallmount kit
